Voute "M" covered walkway with glass cladding

width 2251 x length 2520 x height 2626 to 2826 mm

galvanised steel tube posts 80 x 80 mm

40 x 60 mm steel tube crossbeams, 6 mm thick UV-treated cellular polycarbonate panels. Aluminium profile side rails, curved aluminium profile hoops

extension module, length 2520 mm

painted on galvanised steel in our colours

RAL 3020, RAL 3004, RAL 5010, RAL 6005, RAL 8017, RAL 7044, RAL 9010, RAL 9005, Procity® Grey, Corten effect

on galvanised base plates, height-adjustable feet (max 200 mm), expansion anchors included. Square concrete blocks 400 x 400 mm and 400 mm high

glass side cladding for initial module ref. 599812 and extension module ref. 599813
