Total height with curved head:
- 1238 mm (Ø 160 mm)
- 1265 mm (Ø 219 mm)
- 1286 mm (Ø 273 mm)
Recommended above-ground height: 800 mm
Gauge 4 mm
3 available versions:
- with domed steel top
- without top
- with stainless steel top cap (only in Ø 219 mm)
Supplied empty, the bollard is fitted with a lifting eyelet for easy installation with a lifting machine.
Fill the bollard with reinforcement steel bars* and then with concrete then adding the curve head, held in place by its hook.
